CVI-8CH62BLF - A Bundle of PVR-P8-1VC,8 Channel Penta-brid, 1080P, Mini 1U, DVR & 6x LTDHCR6622-28, HDCVI Bullet Camera 30fps 1080P Fixed Lens, 2MP, 2.8mm
Price Sign In For Price
Promotion Sign In For Promotion
Membership Level
Get Points after Purchase
Member(your level)
$0.00
KITS
KITS
KITS
Number of Camera Channels
Number of Camera Channels
8CH
Max. Storage Capacity
Max. Storage Capacity
10TB
Camera Style
Camera Style
Bullet
Resolution
Resolution
2MP
Quantity
Office
TX - Dallas* (your office)
0 pcs
TX - Houston
0 pcs
NJ - Mt Laurel*
0 pcs
AZ - Phoenix
0 pcs
CA - Los Angeles*
0 pcs
- New List
No List
TX - Dallas*
TX - Houston
NJ - Mt Laurel*
AZ - Phoenix
CA - Los Angeles*
PVR-P8-1VC
• No Built-in PoE
• H.265+
• 48Mbps Bandwidth Max
• Resolution: 4M-N/1080P
• 8CH Analog + 4CH IP
• 15fps @1080P
• Max IP Resolution: 6MP
• CVI/TVI/ AHO/Analog Video Input
• 1 SATA up to 10TB
• Alarm over coaxial
• 100M, 1 Network Port
• Broadcast level audio
LTDHCR6622-28
• 2MP
• 1920 × 1080P@30fps
• 2.8mm Fixed Lens
• Color 0.02 lux, BW 0 lux
• IR LED up to 66ft
• CVI/TVI/AHD/Analog
• DWDR, 2D DNR, BLC
• IP67
• DC 12V
• 33ft Passive Infrared
LTDHCR6622-28
| System Overview |
| With the surveillance operators pursuing to HD/UHD which further adds the storage and transmission cost, HDCVI H.265+/H.265 has been released to incredibly decrease the required bitrate while ensuring the video quality in realizing high resolution surveillance such as 4MP/4K. |
| This Series is designed for high cost performance and quality. The range offers a great solution for users facing budget constraints who both require quality and performance. And with the adoption of Smart H.265+/H.265, the series improves encoding efficiency, saving on bandwidth/storage costs, and significantly reducing the Total Cost of Ownership (TCO) |
| Functions |
| Smart H.265+ |
| Smart Codec, H.265+ can reduce up to 90% bit rate and storage requirements compared with H.264 without having to invest in new cameras. |
| HDCVI/AHD/TVI/CVBS/IP Auto-detect |
| The DVR can auto recognize the signal of front-camera without any setting. It makes operation more friendly and convenient. |
| UHD Camera Input |
| This series supports up to 4MP HDCVI camera and 6MP IP camera input. |
| Coaxial Audio/Upgrade/Alarm |
| The integrated design can reduce wiring troubles which makes it much more cost-effective and convenient for installation. |
| Long Distance Transmission |
| The HDCVI system supports long distance transmission over coaxial cable and UTP, max. 700m for 4K/4MP, 800m for 1080P and 1200m for 720P. |
| Smart Fan Design |
| The smart fan can automatically turn on or turn off according to the CPU temperature. This function can effectively reduce the fan noise to provide a better user experience while extending the life of the fan at the same time. |
| Intelligent Video System (IVS) |
| With built-in intelligent video analytics, the DVR has the ability to detect and analyze moving objects for improved video surveillance. The DVR provides optional standard intelligence at the edge allowing detection of multiple object behaviors such as abandoned or missing objects. IVS also supports Tripwire analytics, allowing the camera to detect when a predetermined line has been crossed. |
| Face Detection |
| It is a type technology being used in a variety of applications that search or identify individuals which show front cameras. |
| Smart Search |
| This function helps you get more motion detect video during a short time through drawing a region when playback. It is very useful when an emergency occurs. |
PVR-P8-1VC
| System Overview |
| Experience 1080P full HD video and the simplicity of using existing cabling infrastructure with HDCVI. The Lite series 1080P HDCVI camera features a compact design and offers a high quality image at a friendly price. It offers various vari-focal/fixed lens models with a multi-language OSD and HD/ SD switchable output. Its structural flexibility and high cost-performance makes the camera an ideal choice for SMB solutions. |
| Functions |
| 4 Signals over 1 Coaxial Cable |
| HDCVI technology supports 4 signals to be transmitted over 1 coaxial cable simultaneously, i.e. video, audio*, data and power. Dual-way data transmission allows the HDCVI camera to interact with the HCVR, such as sending control signal or triggering alarm. Moreover, HDCVI technology supports PoC for construction flexibility. |
| * Audio input is available for some models of HDCVI cameras. |
| Long Distance Transmission |
| HDCVI technology guarantees real-time transmission at l ong distance without any loss. It supports up to 800m(1080P)/1200m(720P) trans- mission via coaxial cable, and up to 300m(1080P)/450m(720P) via UTP cable.* |
| *Actual results verified by real-scene testing in LTS's test laboratory. |
| Simplicity |
| HDCVI technology inherits the born feature of simplicity from traditional analog surveillance system, making itself a best choice for investment protection. H DCVI system can s eamlessly upgrade t he traditional ana- log system without replacing existing coaxial cabling. The plug and play approach enables full HD video surveillance without the hassle of configuring a network. |
| Smart IR |
| The camera is designed with microcrystalline LED IR illumination for best lowlight performance. Smart IR is a technology to ensure brightness uniformity in B/W image under low illumination. LTS’s unique Smart IR adjusts to the intensity of camera's infrared LEDs to compensate for the distance of an object, and prevents IR LEDs from overexposing images as the object come closer to the camera. |
| Multi-formats |
| The camera supports multiple video formats including HDCVI, CVBS and other two common HD analog formats in the market. The four formats can be switched over through OSD menu or by PFM820(UTC controller). This feature makes the camera to be compatible with not only HCVRs but also most end users’ existing HD/SD DVRs. |
| Multi-language OSD |
| OSD menu provides multiple image adjustments and function settings to meet the requirements of different monitoring scenes. The OSD menu includes configurations such as backlight mode, day/night, white balance, privacy mask and motion detect. The camera supports 11 languages for OSD menu, namely, Chinese, English, French, German, Spanish, Portuguese, Italian, Japanese, Korean, Russian and Polish. |
| Protection |
| The camera's outstanding reliability is unsurpassed due to its rugged design. The camera is protected against water and dust with IP67 ranking, making it suitable for indoor or outdoor environments. |
| With working temperature range of-40 °C to +60 °C (-40 °F to +140 °F), the camera is designed for extreme temperature environments. |
| Supporting ±25% input voltage tolerance, this camera suits even the most unstable power supply conditions. Its 4KV lightning rating provides pro- tection against the camera and its structure from the effects of lightning. |
| Technical Specification | ||
| Camera | ||
| Image Sensor | 1/2.7" CMOS | |
| Effective Pixels | 1920(H)×1080(V), 2MP | |
| Scanning System | Progressive | |
| Electronic Shutter Speed | NTSC: 1/30~1/100000s | |
| Minimum Illumination | 0.02Lux/F1.85, 30IRE, 0Lux IR on | |
| S/N Ratio | More than 65dB | |
| IR Distance | Up to 20m (66feet) | |
| IR On/Off Control | Auto / Manual | |
| IR LEDs | 12 | |
| Lens | ||
| Lens Type | Fixed lens / Fixed iris | |
| Mount Type | Board-in | |
| Focal Length | 3.6mm (2.8mm, 6mm Optional) | |
| Max Aperture | F1.85 | |
| Angle of View | H: 89.9° (103°, 54.7°) | |
| Focus Control | N/A | |
| Close Focus Distance | 600mm (900mm, 2000mm) 23.62'' (35.43", 78.74'') | |
| DORI Distance | ||
| Note: The DORI distance is a “general proximity” of distance which makes it easy to pinpoint the right camera for your needs. The DORI distance is calculated based on sensor specification and lab test result according to EN 62676-4 which defines the criteria for Detect, Observe, Recognize and Identify respectively. | ||
| DORI Definition | Distance | |
| Detect | 25px/m (8px/ft) | 2.8mm: 42m(139ft) 3.6mm: 53m(175ft) 6mm: 80m(262ft) |
| Observe | 63px/m (19px/ft) | 2.8mm: 17m(55ft) 3.6mm: 21m(70ft) 6mm: 32m(105ft) |
| Recognize | 125px/m (38px/ft) | 2.8mm: 9m(28ft) 3.6mm: 11m(35ft) 6mm: 16m(52ft) |
| Identify | 250ppm (76px/ft) | 2.8mm: 4m(14ft) 3.6mm: 5m(17ft) 6mm: 8m(26ft) |
| Pan / Tilt / Rotation | ||
| Pan/Tilt/Rotation | Pan: 0° ~ 360° Tilt: 0° ~ 90° Rotation: 0° ~ 360° | |
| Video | ||
| Resolution | 1080P (1920×1080) | |
| Frame Rate | 25/30fps@1080P, 25/30/50/60fps@720P | |
| Video Output | 1-channel BNC high definition video output / CVBS video output (Can switch) | |
| Day/Night | Auto (ICR) / Manual | |
| OSD Menu | Multi-language | |
| BLC Mode | BLC / HLC / DWDR | |
| WDR | DWDR | |
| Gain Control | AGC | |
| Noise Reduction | 2D | |
| White Balance | Auto / Manual | |
| Smart IR | Auto / Manual | |
| Certifications | ||
| Certifications | CE (EN55032, EN55024, EN50130-4) FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) UL (UL60950-1+CAN/CSA C22.2 No.60950-1) | |
| Interface | ||
| Audio Interface | N/A | |
| Eelectrical | ||
| Power Supply | 12V DC ±25% | |
| Power Consumption | Max 3.2W (12V DC, IR on) | |
| Environmental | ||
| Operating Conditions | -40°C ~ +60°C (-40°F ~ +140°F) / Less than 90% RH * Start up should be done at above-40°C (-40°F) | |
| Storage Conditions | -40°C ~ +60°C (-40°F ~ +140°F) / Less than 90% RH | |
| Ingress Protection & Vandal Resistance | IP67 | |
| Construction | ||
| Casing | Aluminium | |
| Dimensions | 156.3mm×70mm×70mm (6.15"×2.76"×2.76") | |
| Net Weight | 0.30kg (0.66lb) | |
| Gross Weight | 0.39kg (0.86lb) | |
