LTS Sapphire
LTN6432-P16, 32 CH NVR 1.5U 4SATA 16PoE 4K&H.265 200Mbps HDMI/VGA LTS Sapphire series
Price Sign In For Price
Promotion Sign In For Promotion
Membership Level
Get Points after Purchase
Member(your level)
$24.45
Max. Storage Capacity
Max. Storage Capacity
24TB
Number of Camera Channels
Number of Camera Channels
32CH
Number of PoE Ports
Number of PoE Ports
16 Ports
Resolution
Resolution
8MP
Quantity
Office
TX - Dallas* (your office)
0 pcs
TX - Houston
0 pcs
NJ - Mt Laurel*
0 pcs
AZ - Phoenix
0 pcs
CA - Los Angeles*
0 pcs
- New List
No List
TX - Dallas*
TX - Houston
NJ - Mt Laurel*
AZ - Phoenix
CA - Los Angeles*
• 16 Ports Built-in PoE
• H.265/H.264
• 200MB Bandwidth Max
• Resolution: 8MP
• HDMI(4K: 3840×2160)/VGA(1920×1080)• 1CH/1CH, RCA Audio I/O
• 4 SATA up to 24TB
• Alarm I/O: 16 / 4
• 10/100/1000M, 1 Network Port

Technical Specification | ||
System | ||
Main Processor | Quad-core embedded processor | |
Operating System | Embedded LINUX | |
Display | ||
Interface | 1 HDMI, 1 VGA | |
Resolution | 3840×2160, 1920×1080,
1280×1024, 1280×720, 1024×768 | |
Multi-screen Display | 1/4/8/9/16 | |
OSD | Camera title, Time, Video loss, Camera lock, Motion detection, Recording | |
Video Detection and Alarm | ||
Trigger Events | Recording, PTZ, Tour, Alarm out, Video Push, Email, FTP, Snapshot, Buzzer & Screen tips | |
Video Detection | Motion Detection, MD Zones: 396(22×18), Video Loss & Tampering | |
Alarm input | 16 Channel, Low Level Effective, Green Terminal Interface | |
Relay Output | 4 Channel, NO/NC Programmable, Green Terminal Interface | |
Playback and Backup | ||
Playback | 1/4/8/16 | |
Search Mode | Time/Date, Alarm, MD & Exact search (accurate to second), Smart search | |
Playback Function | Play, Pause, Stop, Rewind,
Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom | |
Backup Mode | USB Device/Network | |
Storage | ||
Internal HDD | 4 SATA III Port, Up to 6 TB capacity for each HDD | |
HDD Mode | Single | |
eSATA | N/A | |
Auxiliary Interface | ||
USB | 2 USB Ports (1 USB2.0, 1 USB3.0) | |
RS232 | 1 Port, for PC Communication and Keyboard | |
RS485 | 1 Port, for PTZ Control | |
Third-party Support | ||
Third-party Support | Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, and more | |
Audio and Video | ||
IP Camera Input | 16/32 Channel | |
Two-way Talk | 1 Channel Input, 1 Channel Output, RCA | |
Recording | ||
Compression | H.265/H.264 | |
Resolution | 8Mp/ 6Mp/ 5MP/ 4MP/ 3MP/ 1080P/ 1.3MP/ 720P etc. | |
Record Rate | 200Mbps | |
Bit Rate | 16Kbps ~ 20Mbps Per Channel | |
Record Mode | Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Tampering, Video Loss), Stop | |
Record Interval | 1 ~ 120 min (default: 60
min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec | |
Network | ||
Interface | 1 RJ-45 Ports(10/100/1000Mbps) | |
Ethernet Port | 1 Independent 1000Mbps Ethernet Port | |
PoE | 16 ports (IEEE802.3af/at) | |
Network Function | HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP,
DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, IP Search (Support IP camera, DVR, NVS, etc.), Easy4ip | |
Max. User Access | 128 users | |
Smart Phone | iPhone, iPad, Android | |
Interoperability | ONVIF 2.4, CGI Conformant | |
Electrical | ||
Power Supply | AC100V ~ 240V, 50 ~ 60 Hz | |
Power Consumption | NVR: <13.7W (Without HDD) | |
PoE: Max 25.5w for single port, 150w in total | ||
Environmental | ||
Operating Conditions | -10°C ~ +55°C (+14°F ~ +131°F), 86 ~ 106kpa | |
Storage Conditions | -20°C ~ +70°C (-4°F ~ +158°F), 0 ~ 90% RH | |
Construction | ||
Dimensions | 1.5U, 440mm×411.1mm×76mm (17.3" x 16.2" x 3.0") | |
Net Weight | 4.7kg (10.4lb) (without HDD) | |
Gross Weight | 7.5kg(16.5 lb)(without HDD) | |
Certifications | ||
CE | EN55032, EN55024, EN50130-4, EN60950-1 | |
FCC | Part 15 Subpart B, ANSI C63.4-2014 | |
UL | UL60950-1+CAN/CSA C22.2 No.60950-1 |
