LTCMIP7923LPR-32R, Platinum Network LPR IP Camera, 2MP, 8-32mm, True WDR

Price Sign In For Price

Promotion Sign In For Promotion

Membership Level

Price after Using Points

Get Points after Purchase

Gold(your level)

$577.44

$11.98

Camera Style

Bullet

Resolution

2MP

Quantity

Office

Inventory

MD - Lanham (your office)

0 pcs

NJ - Mt Laurel

0 pcs

TX - Houston

0 pcs

GA - Norcross

0 pcs

CA Main Warehouse

0 pcs

Camera
Image Sensor	1/1.8" Progressive Scan CMOS
Min. Illumination	Color: 0.0027 Lux @ (F1.4, AGC ON), 0 Lux with IR
Shutter Speed	1 s to 1/100,000 s
Slow Shutter	Support
Lens	8 mm to 32 mm, F1.6, horizontal field of view: 42° to 13.5°
Auto-iris	DC drive
DNR	3D DNR
Wide Dynamic Range	120dB
Compression Standard
Video Compression	H.264 / MJPEG/H.264 Zip+
H.264 Type	Baseline Profile/Main Profile/High Profile
Video Bit Rate	32 Kbps ~ 8 Mbps
Audio Compression	G.711/G.722.1/G.726/MP2L2
Audio Bit rate	64Kbps(G.711) / 16Kbps(G.722.1) / 16Kbps(G.726) / 32-128Kbps(MP2L2)
Max. Resolution	1920 × 1080
Frame Rate	60Hz: 60fps (1920 × 1080, 1280 × 960, 1280 × 720)
	50Hz: 50ps(1920 × 1080, 1280 × 960, 1280 × 720)
Image Setting	Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser
Day/Night Switch	Auto/Schedule/Triggered by Alarm In
ROI	Support 4 fixed region for each stream, and dynamic tracking
Network
Network Storage	NAS (Support NFS,SMB/CIFS), ANR
Alarm Trigger	Motion detection, Tampering alarm, Network disconnect, IP address conflict, Storage exception
Protocols	TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS , RTP, RTS P, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6,
General	One-key reset, Flash-prevention, dual stream, heartbeat, mirror, password protection, privacy mask, watermark, IP address filtering, Anonymous access
Standard	ONVIF (PROFILE S, PROFILE G), ISAPI
Interface
Communication Interface	1 RJ45 10M/100M Ethernet port
On-board storage	Built-in Micro SD/SDHC/SDXC slot, up to 128GB
Reset	Yes
General
Working Temperature/Humidity	- 22 ° F ~ 14 0°F (- 30 °C ~ 60 °C)
	Humidity 95% or les s (non- condens ing)
Power Supply	DC12V ± 10%, PoE (802.3at, class 4)
Power Consumption	12 VDC, max. 13.3 W, 1.2 A; PoE, max. 17.6 W, 0.3 A to 0.5 A
Weatherproof Ratings	IP67
Dimensions	13.72″ × 4.5″ × 4.4″(348.38 × 114.18 × 111.73 mm)
Weight	4.57lbs (2075 g)
