LTCMIP7923LPR-32R, Platinum Network LPR IP Camera, 2MP, 8-32mm, True WDR
Price Sign In For Price
Promotion Sign In For Promotion
Membership Level
Price after Using Points
Get Points after Purchase
Camera Style
Camera Style
Bullet
Resolution
Resolution
2MP
Quantity
Office
- New List
No List
- License Plate Recognition up to 60MPH
- 2MP High Definition
- 8 – 32mm Motorized Lens with Auto Focus
- 1920 x 1080P@60fps
- Infrared IR up to 328 feet
- H.264, H.264 Zip+
- Ultra Low Lux 0.0027 @ F1.4
- True WDR 120dB
- IP67
- MicroSD Slot up to 128GB
- Audio I/O & Alarm I/O
- DC 12V, PoE
- Applicable to LTN86XX / LTN89XX / LTN07XX

Camera | |
Image Sensor | 1/1.8" Progressive Scan CMOS |
Min. Illumination | Color: 0.0027 Lux @ (F1.4, AGC ON), 0 Lux with IR |
Shutter Speed | 1 s to 1/100,000 s |
Slow Shutter | Support |
Lens | 8 mm to 32 mm, F1.6, horizontal field of view: 42° to 13.5° |
Auto-iris | DC drive |
DNR | 3D DNR |
Wide Dynamic Range | 120dB |
Compression Standard | |
Video Compression | H.264 / MJPEG/H.264 Zip+ |
H.264 Type | Baseline Profile/Main Profile/High Profile |
Video Bit Rate | 32 Kbps ~ 8 Mbps |
Audio Compression | G.711/G.722.1/G.726/MP2L2 |
Audio Bit rate | 64Kbps(G.711) / 16Kbps(G.722.1) / 16Kbps(G.726) / 32-128Kbps(MP2L2) |
Image | |
Max. Resolution | 1920 × 1080 |
Frame Rate | 60Hz: 60fps (1920 × 1080, 1280 × 960, 1280 × 720) |
50Hz: 50ps(1920 × 1080, 1280 × 960, 1280 × 720) | |
Image Setting | Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser |
Day/Night Switch | Auto/Schedule/Triggered by Alarm In |
ROI | Support 4 fixed region for each stream, and dynamic tracking |
Network | |
Network Storage | NAS (Support NFS,SMB/CIFS), ANR |
Alarm Trigger | Motion detection, Tampering alarm, Network disconnect, IP address conflict, Storage exception |
Protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS , RTP, RTS P, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, |
General | One-key reset, Flash-prevention, dual stream, heartbeat, mirror, password protection, privacy mask, watermark, IP address filtering, Anonymous access |
Standard | ONVIF (PROFILE S, PROFILE G), ISAPI |
Interface | |
Communication Interface | 1 RJ45 10M/100M Ethernet port |
On-board storage | Built-in Micro SD/SDHC/SDXC slot, up to 128GB |
Reset | Yes |
General | |
Working Temperature/Humidity | - 22 ° F ~ 14 0°F (- 30 °C ~ 60 °C) |
Humidity 95% or les s (non- condens ing) | |
Power Supply | DC12V ± 10%, PoE (802.3at, class 4) |
Power Consumption | 12 VDC, max. 13.3 W, 1.2 A; PoE, max. 17.6 W, 0.3 A to 0.5 A |
Weatherproof Ratings | IP67 |
Dimensions | 13.72″ × 4.5″ × 4.4″(348.38 × 114.18 × 111.73 mm) |
Weight | 4.57lbs (2075 g) |
