LTCMIP7853W-SZ, Platinum Varifocal Motorized Dome IP Camera, 5MP, 2.8-12mm, True WDR, Matrix IR 2.0, Audio/Alarm

SKU: LTCMIP7853W-SZ

Promotion Sign In For Promotion

Price Sign In For Price

Camera Style

Dome

Resolution

5MP

Quantity

Add to My List

Camera
Image Sensor	1/2.9" Progressive Scan CMOS
Min. Illumination	0.01Lux @ (F1.2, AGC ON), 0.01 4 Lux @(F1.4, AGC ON), 0 Lux with IR
Shutter Speed	1/3 s to 1/100,000 s
Lens	2.8-12mm@F1.4, Motorized Lens, AoV 88°- 29°
Lens Mount	Φ14
Day & Night	IR cut filter
DNR	3D DNR
Wide Dynamic Range	120dB
Angle Adjustment	Pan:0°~ 355°, Tilt: 0°~ 75°, Rotation: 0°~ 355°
Compression Standards
Video Compression	Main stream: H.265+/H.265/H.264 Zip+/H.264
	Sub stream: H.265+/H.265/H.264 Zip+/H.264/MJPEG
	Third stream: H.265+/H.265/H.264 Zip+/H.264
H.264 Type	Main / High Profile
H.265 Type	Main Profile
Video Bit Rate	32 Kbps to 16 Mbps
Audio Compression	G722.1/G711ulaw/G711alaw/G726/MP2L2
Audio Bit rate	32 to 128kbps
General
Operating Conditions	-40 °F - 140 °F (-40 °C - 60° C), Humidity 90% or less (non-condensing)
Power Supply	DC12V
Power Consumption	12 VDC, 0.8A, max. 10W; PoE ( 802.3af, 37V to 57V), 0.1A to 0.3A, max. 11.5W
IR Range	Up to 100ft (30m)
Protection Level	IP67
Impact Protection	IK10
Dimensions	Φ 6 .04” × 5.24”(Φ 153.4× 133.1 mm)
Weight	2.84lbs (1287g )
