LTCMIP7853W-SZ, Platinum Varifocal Motorized Dome IP Camera, 5MP, 2.8-12mm, True WDR, Matrix IR 2.0, Audio/Alarm
Price Sign In For Price
Promotion Sign In For Promotion
Membership Level
Get Points after Purchase
Member(your level)
$2.79
Camera Style
Camera Style
Dome
Resolution
Resolution
5MP
Quantity
Office
TX - Dallas* (your office)
0 pcs
TX - Houston
0 pcs
NJ - Mt Laurel*
0 pcs
AZ - Phoenix
0 pcs
CA - Los Angeles*
0 pcs
- New List
No List
TX - Dallas*
TX - Houston
NJ - Mt Laurel*
AZ - Phoenix
CA - Los Angeles*
- 5MP High Definition, Up to 2560x1920@20fps
- 2.8-12mm Varifocal Motorized Lens with Smart Focus
- Matrix IR 2.0, IR Range up to 100 feet
- H.265, H.265+, H.264, H.264+ Ready
- True WDR 120dB
- IP67
- MicroSD Slot up to 128GB
- Audio I/O, Alarm I/O
- DC 12V, PoE
- Built-in Junction Box
Camera | |
Image Sensor | 1/2.9" Progressive Scan CMOS |
Min. Illumination | 0.01Lux @ (F1.2, AGC ON), 0.01 4 Lux @(F1.4, AGC ON), 0 Lux with IR |
Shutter Speed | 1/3 s to 1/100,000 s |
Lens | 2.8-12mm@F1.4, Motorized Lens, AoV 88°- 29° |
Lens Mount | Φ14 |
Day & Night | IR cut filter |
DNR | 3D DNR |
Wide Dynamic Range | 120dB |
Angle Adjustment | Pan:0°~ 355°, Tilt: 0°~ 75°, Rotation: 0°~ 355° |
Compression Standards | |
Video Compression | Main stream: H.265+/H.265/H.264 Zip+/H.264 |
Sub stream: H.265+/H.265/H.264 Zip+/H.264/MJPEG | |
Third stream: H.265+/H.265/H.264 Zip+/H.264 | |
H.264 Type | Main / High Profile |
H.265 Type | Main Profile |
Video Bit Rate | 32 Kbps to 16 Mbps |
Audio Compression | G722.1/G711ulaw/G711alaw/G726/MP2L2 |
Audio Bit rate | 32 to 128kbps |
General | |
Operating Conditions | -40 °F - 140 °F (-40 °C - 60° C), Humidity 90% or less (non-condensing) |
Power Supply | DC12V |
Power Consumption | 12 VDC, 0.8A, max. 10W; PoE ( 802.3af, 37V to 57V), 0.1A to 0.3A, max. 11.5W |
IR Range | Up to 100ft (30m) |
Protection Level | IP67 |
Impact Protection | IK10 |
Dimensions | Φ 6 .04” × 5.24”(Φ 153.4× 133.1 mm) |
Weight | 2.84lbs (1287g ) |
