LTCMHT1722W-CF, Platinum HD-TVI Turret Camera, 2.1MP, 3.6mm, True WDR, Color 24/7
Price Sign In For Price
Promotion Sign In For Promotion
Membership Level
Get Points after Purchase
Member(your level)
$3.22
Camera Style
Camera Style
Turret
Resolution
Resolution
2.1MP
Quantity
Office
TX - Dallas* (your office)
0 pcs
TX - Houston
0 pcs
NJ - Mt Laurel*
0 pcs
AZ - Phoenix
0 pcs
CA - Los Angeles*
0 pcs
- New List
No List
TX - Dallas*
TX - Houston
NJ - Mt Laurel*
AZ - Phoenix
CA - Los Angeles*
- 2 MP high performance CMOS
- 1920 × 1080 resolution
- Full time color
- 3.6 mm fixed lens
- Up to 66ft(20 m) white light distance
- 3D DNR, true WDR
- 4 in 1 video output (switchable TVI/AHD/CVI/CVBS)
- IP67
- OSD menu via UTC technology with Platinum DVR
- Color 24/7

Camera | |
Image Sensor | 2 MP CMOS image sensor |
Resolution | 1920 (H) × 1080 (V) |
PAL: 1080p@25fps NTSC: 1080p@30fps | |
Frame Rate | |
Min. illumination | Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light |
Shutter Time | PAL: 1/25 s to 1/50, 000 s |
NTSC: 1/30 s to 1/50, 000 s | |
Slow Shutter | Max. 16x |
Lens | 3.6 mm fixed lens |
Horizontal Field of View | 83.6° (3.6 mm) |
Lens Mount | M16 |
Day & Night | Color |
Angle Adjustment | Pan: 0° to 360°; Tilt: 0° to 75°; Rotate: 0° to 360° |
Synchronization | Internal synchronization |
WDR (Wide Dynamic Range) | 120 dB |
Menu | |
AGC | Yes |
White Balance | Auto/Manual |
BLC (Backlight Compensation) | Yes |
Privacy Mask | 4 programmable privacy masks |
Motion Detection | 4 programmable areas |
WDR | Yes |
Functions | Brightness, Sharpness, 3D DNR, Mirror, Smart light |
Interface | |
Video Output | 1 HD analog output |
Switch Button | TVI/AHD/CVI/CVBS |
General | |
Operating Conditions | -40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation) |
Power Supply | 12 VDC ±25% |
Power Consumption | Max. 3 W |
Protection Level | IP67 |
Material | Main Body: Metal, Mounting Base: Plastic |
White Light | Up to 66ft(20 m) |
Communication | Up the coax, TVI output |
Dimensions | Ø 109.82 mm × 85.56 mm ( Ø 4.32" × 3.37") |
Weight | Approx. 336 g (0.74 lb.) |
