LTD8308K-ET, Platinum Professional 8 Channel HD-TVI DVR, 1U, SATA up to 12TB, No Pre-Installed Storage
Price Sign In For Price
Promotion Sign In For Promotion
Membership Level
Get Points after Purchase
Member(your level)
$0.73
Number of Camera Channels
Number of Camera Channels
8CH
Max. Storage Capacity
Max. Storage Capacity
12TB
Quantity
Office
TX - Dallas* (your office)
0 pcs
TX - Houston
0 pcs
NJ - Mt Laurel*
0 pcs
AZ - Phoenix
0 pcs
CA - Los Angeles*
0 pcs
- New List
No List
TX - Dallas*
TX - Houston
NJ - Mt Laurel*
AZ - Phoenix
CA - Los Angeles*
- H.265 Pro+/H.265 Pro/H.265 video compression
- HDTVI/AHD/CVI/CVBS/IP video input
- Up to 12/24-ch IP camera inputs (up to 6 MP)
- Max. 800 m for 1080p and 1200 m for 720p HDTVI signal transmission
- Up to 10 TB capacity per HDD
- Applicable to no more than 2MP pixels HD-TVI Camera/no more than 4MP pixels HD-CVI Camera

Model Name | LTD8308K-ET |
Video Compression | H.265+/H.265/H.264 Zip+/H.264 |
Audio Compression | G.711u |
IP Video Input | 2-ch, Up to 4 MP resolution, supports H.265+/H.265/H.264 Zip+/H.264 IP cameras |
HD-TVI Input | 3MP, 1080p30,1080p25, 720p60, 720p50,720p30,720p25 |
Note: 3MP signal input is only available for channel 1 | |
Support | HDCVI, AHD, 1080p25, 1080p30, 720p25, 720p30 |
CVBS Input | Support |
Simultaneous Playback | 8CH |
Audio Input | 1-ch, RCA (2.0 Vp-p, 1 KΩ) |
HDMI VGA Output | 1 -ch , 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60 Hz |
Encoding Resolution | When 1080p Lite mode not enabled: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF; |
When 1080p Lite mode enabled: 3 MP/1080p lite/720p lite/VGA/WD1/4CIF/CIF | |
CVBS Output | 1-ch, BNC (1.0 Vp-p, 75 kΩ), resolution: PAL: 704 × 576, NTSC: 704 × 480 |
USB interface | Front panel: 1 ×USB 2.0, Rear panel: 1 ×USB 3.0 |
Two Way Audio Input | 1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the1st audio input) |
Capacity | 2 SATA/ Up to 8TB capacity for each disk |
Casing | 1U |
Power supply | 12 VDC |
Consumption | ≤ 7.5W |
Operating Temperature | -10 °C ~ +55 °C(14°F - 131°F) |
Product Dimension | 380 × 320 × 48 mm (15.0 × 12.6 × 1.9 inch) |
Product Weight | ≤1.78Kg (3.9 lb) |
