LTD8508K-DT, Platinum 8 Channel 4K Deep Learning DVR, 1U, 2 SATA up to 16TB, No Pre-Installed Storage
Price Sign In For Price
Promotion Sign In For Promotion
Membership Level
Get Points after Purchase
Member(your level)
$1.66
Number of Camera Channels
Number of Camera Channels
8CH
Max. Storage Capacity
Max. Storage Capacity
16TB
Quantity
Office
TX - Dallas* (your office)
0 pcs
TX - Houston
0 pcs
NJ - Mt Laurel*
0 pcs
AZ - Phoenix
0 pcs
CA - Los Angeles*
0 pcs
- New List
No List
TX - Dallas*
TX - Houston
NJ - Mt Laurel*
AZ - Phoenix
CA - Los Angeles*
- 4-ch Deep Learning,
- 8 Turbo HD/CVI / AHD / CVBS self-adaptive interfaces input,
- 8-ch video&4-ch audio input,
- 4-ch IP video input, 2 SATA interfaces,
- H.265/H.265+ compression, 8MP: 8fps, 5MP: 12fps, 4MP: 15fps, 3MP: 18fps, 1920×1080P: 25(P)/30(N) fps/ch,
- 4K UHD output, alarm I/O: 8/4, support CVBS output, 380 1U case

VIDEO/AUDIO INPUT | |
Video Compression | H.265+/H.265/H.264 Zip+/H.264 |
Video Input | 8ch BNC interface (1.0Vp-p, 75 Ω), supporting coaxitron connection |
IP Input | 2-ch, Up to 6 MP resolution |
HDTVI input | 5 MP, 4 MP, 3 MP, 1080p30, 1080p25, 720p60, 720p50, 720p30, 720p25 |
AHD input | 1080p25, 1080p30, 720p25, 720p30 |
HDCVI input | 1080p25, 1080p30, 720p25, 720p30 |
CVBS input | Support |
Audio Compression | G.711u |
Audio Input | 4-CH, RCA (2.0 Vp-p kΩ) |
Two-Way Audio Input | 1-CH, RCA (2.0 Vp-p kΩ) |
VIDEO/AUDIO OUTUPUT | |
HDMI/VGA Output | VGA: 1 -c h , 192 0 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60 Hz HDMI: 1-ch, 4K (3840 × 2160)/30Hz, 2K(2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
Encoding resolution | 5 MP/4 MP/3MP/1080p/720p/WD1/4CIF/VGA/CIF |
CVBS output | 1-ch, BNC (1.0 Vp-p, 1 kΩ), resolution: PAL: 704 × 576, NTSC: 704 × 480 |
Frame Rate | Main stream: 5MP@12fps/4 MP@15fps/3 MP@18fps,1080p/720p/WD1/4CIF/VGA/CIF@25fps(P)/30fps(N) Sub-stream: WD1/4CIF/CIF@25fps (P)/30fps (N) |
Video Bit Rate | 32 Kbps-10 M bps |
Audio Output | 1-ch, RCA (Linear, 1 kΩ) |
Audio Bit Rate | 64 Kbps |
Dual Stream | Support |
Stream Type | Video, Video & Audio |
Synchronous Playback | 8ch |
NETWORK | |
Remote Connections | 128 |
Network Protocols | TCP/IP, PPPoE, DHCP, PT Cloud P2P, DNS, DDNS, NTP, SAD P, NFS, iSCSI, UPnP™, HTTPS, ONVIF |
HARD DISK | |
SATA | 2 SATA |
Capacity | Up to 8TB capacity for each disk |
EXTERNAL INTERFACE | |
Network interface | 1:10M / 100Mself-adapt ive Ethernet interface |
Serial interface | RS-4 85 |
USB Port | 2 × USB 2.0 |
Alarm In/Out | 8/4 |
GENERAL | |
Power supply | DC12V |
Consumption | ≤ 20W |
Working temperature | -10 °C ~ +55 °C(14°F - 131°F) |
Working humidity | 10% ~ 90% |
Chassis | 1U |
Dimensions (WxDxH) | 380 × 320 × 45 mm (15.0 × 12.6 × 1.8 inch) |
Weight | ≤2 Kg (4.4 lb) |
