LTD8432T-FA, Platinum Enterprise 32 Channel HD-TVI DVR, 1.5U, 4 SATA up to 24TB, No Pre-Installed Storage

Price Sign In For Price

Promotion Sign In For Promotion

Membership Level

Get Points after Purchase

Member(your level)

$11.98

Number of Camera Channels

32CH

Max. Storage Capacity

24TB

Quantity

Office

Inventory

TX - Dallas* (your office)

0 pcs

TX - Houston

0 pcs

NJ - Mt Laurel*

0 pcs

AZ - Phoenix

0 pcs

CA - Los Angeles*

0 pcs

Video/Audio Input
Video Compression	H.264
Analog and HD-TVI Video Input	32CH/ BNC (1.0 Vp-p, 75 Ω), PAL/NTSC self-adaptive
IP Input	Up to 8CH (1080p@30fps)
Audio Compression	G.711u
Audio Input	4-ch, RCA (2.0 Vp-p, 1kΩ)
Two-Way Audio Input	1-ch, RCA (2.0 Vp-p, 1kΩ)
Video/Audio Output
HDMI/ VGA Output	1920 x 1080/60Hz, 1280 x 1024/ 60Hz, 1280 x 720/ 60Hz, 1024 x 768/60Hz
Encoding Resolution	Main Stream: 1080P (non-real-time) / 720P / VGA / WD1 / 4CIF / CIF/
	Sub-Stream: WD1(non-real-time)/ 4CIF(non-real-time)/ CIF/ QCIF/ QVGA
Frame Rate	Main Stream: 1/16fps~ Real time frame rate/
	Sub-Stream: 1/16fps~ Real time frame rate
Video Bit Rate	32Kbps-4Mbps
Audio Output	1-CH, RCA (Linear, 1 kΩ)
Audio Bit Rate	64 Kbps
Dual-Stream	Support
Stream Type	Video, Video & Audio
Synchronous Playback	32CH
Playback Resolution	1080P/ 720P/ VGA/ WD1/ 4CIF/ CIF QVGA/ QCIF
Network
Remote Connections	128
Network Protocols	TCP/IP, PPPoE, DHCP, DNS, DDNS, NTP, SADP, SMTP, SNMP, NFS, iSCSI, UPnP™, HTTPS
Hard Disk
SATA	4 SATA Interfaces for 4 HDDs; 1 eSATA interface
Capacity	Up to 6TB capacity for each disk
External Interface
Network Interface	1:10M/ 100M/ 1000M self adaptive Ethernet interface
Serial Interface	RS-232, RS-485, Keyboard
USB Port	3xUSB2.0
Alarm In/Out	4 In / 1 Out
General
Power Supply	100~240VAC, 47~63HZ
Consumption	≤65W
Working Temperature	-10°C ~ 55°C(14°F-131°F)
Working Humidity	10%~90%
Chassis	19-inch rack mounted 1.5U Chassis
Dimesnsions (WxDxH)	445 x 390 x 70mm (17.5x15.3x2.7inch)
Weight	≤5Kg (11.0lb)
