LTS
LTCMIP7923LPR-20, License Plate Recognition(LPR) IP Bullet Network Cammera, 2MP, 8-20mm, True WDR
SKU: LTCMIP7923LPR-20
You get 3737 reward points per unit after placing order
Promotion Sign In For Promotion
Price Sign In For Price
Use reward points to enjoy maxinum $38.87 discount per unit
Bullet
2MP
Add to My List
- Create a list
- 2.1MP High Definition
- True WDR, 120dB
- 3D DNR, BLC, Intelligent H.264 Zip+
- Audio I/O, Alarm I/O
- IP66
- DC 12V/PoE
| Camera | |
| Image Sensor | 1/2.8" Progressive Scan CMOS |
| Min. Illumination | 0.01Lux @(F1.2,AGC ON), 0.014 Lux @(F1.4,AGC ON), 0 Lux with IR |
| Shutter Speed | 1/3 s to 1/10,000 s |
| Slow Shutter | Support |
| Lens | 8 - 20 mm @ F1.4，Motorized Lens |
| Lens Mount | Φ14 |
| DNR | 3D DNR |
| Wide Dynamic Range | 120dB |
| Compression Standard | |
| Video Compression | H.264 / MJPEG/H.264 Zip+ |
| H.264 Type | Main Profile |
| Video Bit Rate | 32 Kbps ~ 8 Mbps |
| Audio Compression | G.711/G.722.1/G.726/MP2L2 |
| Audio Bit rate | 64Kbps(G.711) / 16Kbps(G.722.1) / 16Kbps(G.726) / 32-128Kbps(MP2L2) |
| Image | |
| Max. Resolution | 1920 × 1080 |
| Frame Rate | 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720) |
| 50Hz: 25fps(1920 × 1080, 1280 × 960, 1280 × 720) | |
| Image Setting | Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser |
| BLC | Support, zone configurable |
| ROI Codec | Support |
| Network | |
| Network Storage | NAS (Support NFS,SMB/CIFS), ANR |
| Alarm Trigger | Motion detection, Tampering alarm, Network disconnect, IP address conflict, Storage exception |
| Protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS , RTP, RTS P, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| General | One-key reset, Flash-prevention, dual stream, heartbeat, mirror, password protection, privacy mask, watermark, IP address filtering, Anonymous access |
| Standard | ONVIF (PROFILE S, PROFILE G), PSIA, CGI, ISAPI |
| Interface | |
| Communication Interface | 1 RJ45 10M/100M Ethernet port |
| On-board storage | Built-in Micro SD/SDHC/SDXC slot, up to 128GB |
| Reset | Yes |
| General | |
| Working Temperature/Humidity | - 22 ° F ~ 14 0°F (- 30 °C ~ 60 °C) |
| Humidity 95% or les s (non- condens ing) | |
| Power Supply | DC12V ± 10%, PoE (802.3af) |
| Power Consumption | Max. 5.5W (Max. 7.5 W with IR cut filter on) |
| Weatherproof Ratings | IP66 |
| Dimensions | 3.7” × 4.1” × 10.2”(95×105×258.6 mm) |
| Weight | 2.65lbs (1200 g) |
