LTD5104C-KL, 4 CH Penta-brid 4K 1SATA H.265+/H.265 4+2CH IP upto 8MP, Smart Search and Intelligent Video System LTS Sapphire series
Price Sign In For Price
Promotion Sign In For Promotion
Membership Level
Price after Using Points
Get Points after Purchase
Member(your level)
$78.32
$3.56
Max. Storage Capacity
Max. Storage Capacity
10TB
Number of Camera Channels
Number of Camera Channels
4CH
Resolution
Resolution
4K
Quantity
Office
CA - Los Angeles (your office)
21 pcs
TX - Houston
11 pcs
CA - San Francisco
6 pcs
NJ - Mt Laurel
38 pcs
AZ - Phoenix
10 pcs
CA Main Warehouse
0 pcs
- New List
No List
CA - Los Angeles
TX - Houston
CA - San Francisco
NJ - Mt Laurel
AZ - Phoenix
CA Main Warehouse
• H.265+
• 24Mbps Bandwidth Max
• Resolution: 4K
• 4CH Analog + 2CH IP
• 30fps@1080P;15fps@4MP;7fps@4K
• CVI/ TVI/ AHD/Analog Video Input
• 1 SATA up to 10TB
• Alarm over coaxial
• 100M, 1 Network Port
| System Overview |
| With the surveillance operators pursuing to HD/UHD which further adds the storage and transmission cost, HDCVI H.265+/H.265 has been released to incredibly decrease the required bitrate while ensuring the video quality in realizing high resolution surveillance such as 4MP/4K. |
| The Lite Series is designed for high cost performance and quality. The range offers a great solution for users facing budget constraints who both require quality and performance. And with the adoption of Smart H.265+/H.265, the series improves encoding efficiency, saving on bandwidth/storage costs, and significantly reducing the Total Cost of Ownership (TCO). |
| Functions |
| Smart H.265+ |
| Smart Codec, H.265+ can reduce up to 80% bit rate and storage requirements compared with H.264 without having to invest in new cameras. |
| HDCVI/AHD/TVI/CVBS Auto-detect |
| The XVR can auto recognize the signal of front-camera without any setting. It makes operation more friendly and convenient. |
| 8MP Resolution |
| The XVR supports up to 8MP HD resolution (3840 x 2160) HDCVI camera |
| and IP camera input. |
| Coaxial Audio/Upgrade/Alarm |
| The integrated design can reduce wiring troubles which makes it much more |
| cost-effective and convenient for installation. |
| Long Distance Transmission |
| The HDCVI system supports long distance transmission over coaxial cable and UTP, max. 700m for 4K/4MP, 800m for 1080P and 1200m for 720P. |
| Smart Fan Design |
| The smart fan can automatically turn on or turn off according to the CPU temperature. This function can effectively reduce the fan noise to provide a better user experience. |
| Intelligent Video System (IVS) |
| With built-in intelligent video analytics, the XVR has the ability to detect and analyze moving objects for improved video surveillance. The XVR provides optional standard intelligence at the edge allowing detection of multiple object behaviors such as abandoned or missing objects. IVS also supports Tripwire analytics, allowing the camera to detect when a pre- determined line has been crossed. |
| Face Detection |
| It is a typical technology being used in a variety of applications for searching or identification of individuals. |
| Smart Search |
| This function helps you get more motion detect video during a short time through drawing a region when playback. It is very useful when an emergency occurs. |
| Technical Specification | |
| System | |
| Main Processor | Embedded Processor |
| Operating System | Embedded LINUX |
| Video and Audio | |
| Analog Camera Input | 4 Channel, BNC |
| HDCVI Camera | 4K, 6MP, 4MP, 1080P@25/30fps, 720P@50/60fps, 720P@25/30fps |
| AHD Camera | 5MP, 4MP, 3MP, 1080P@25/30, 720P@25/30fps |
| TVI Camera | 5MP, 4MP, 3MP, 1080P@25/30, 720P@25/30fps |
| CVBS Camera | PAL/NTSC |
| IP Camera Input | 4+2 Channel, each channel up to 8MP |
| Audio In/Out | 1/1, RCA |
| Two-way Talk | Reuse audio in/Out, RCA |
| Recording | |
| Compression | H.265+/H.265/H.264+/H.264 |
| Resolution | 4K, 6MP, 5MP, 4K-N, 4MP, 3MP, 4M-N, 1080P, 720P, 960H, D1,CIF, QCIF |
| Record Rate | Main stream: the 1st channel 4K(1~7fps), 6MP(1~10fps), 5MP(1~12fps),
4K-N/4MP/3MP(1~15fps), others 4K-N/4MP/3MP(1~15fps); 4M-N/1080P/720P/960H/D1/CIF/QCIF (1~25/30fps) Sub steram:960H(1~15fps); D1/CIF/QCIF(1~25/30fps) |
| Bit Rate | 1Kbps ~ 8192Kbps Per Channel |
| Record Mode | Manual, Schedule (General, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop |
| Record Interval | 1 ~ 60 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec |
| Display | |
| Interface | 1 HDMI, 1 VGA |
| Resolution | HDMI:2560×1440, 1920×1080, 1280×1024, 1280×720 VGA: 1920×1080, 1280×1024, 1280×720 |
| Multi-screen Display | When IP extension mode
not enabled: 1/4 When IP extension mode enabled: 1/4/6 |
| OSD | Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
| Network | |
| Interface | 1 RJ-45 Port (100M) |
| Network Function | HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP,
DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, P2P,IP Search (Support LTS IP camera, DVR, NVS, etc.) |
| Max. User Access | 128 users |
| Smart Phone | iPhone, iPad, Android |
| Interoperability | ONVIF 16.12, CGI Conformant |
| Video Detection and Alarm | |
| Trigger Events | Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips |
| Video Detection | Motion Detection, MD Zones: 396 (22 × 18), Video Loss, Tampering and Diagnosis |
| Alarm input | N/A |
| Relay Output | N/A |
| Playback and Backup | |
| Playback | 1/4 |
| Search Mode | Time /Date, Alarm, MD and Exact Search (accurate to second) |
| Playback Function | Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom |
| Backup Mode | USB Device/Network |
| Storage | |
| Internal HDD | 1 SATA Port, up to 10TB capacity |
| eSATA | N/A |
| Auxiliary Interface | |
| USB | 2 USB Ports (2 USB 2.0) |
| RS232 | N/A |
| RS485 | 1 Port, for PTZ Control |
| Electrical | |
| Power Supply | DC12V/2A |
| Power Consumption | <10W (Without HDD) |
| Construction | |
| Dimensions | Mini 1U, 325mm×255mm×55mm (12.8" x 10" x 2.2") |
| Net Weight | 1.5kg (3.3 lb) (without HDD) |
| Gross Weight | 2kg (4.4lb) |
| Installation | Desktop installation |
| Environmental | |
| Operating Conditions | -10°C ~ +55°C (+14°F ~ +131°F), 0~ 90% RH |
| Storage Conditions | -20°C ~ +70°C (-4°F ~ +158°F) , 0~ 90% RH |
| Third-party Support | |
| Third-party Support | Unisight EmPower, Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more |
| Certifications | |
| Certifications | FCC: Part 15 Subpart B |
| CE: CE-LVD: EN 60950-1/IEC 60950-1 CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN 50130,EN 55024 |
|
| UL: UL 60950-1 | |
